Router TP-Link Archer AX12 AX1500
- Wi-Fi 6 Technology: Archer AX12 is equipped with the latest wireless technology, Wi-Fi 6, for faster speeds, greater capacity, and reduced network congestion.
- Next-Generation 1.5 Gbps Speeds: The dual-band Archer AX12 router reaches even faster speeds of up to 1.5 Gbps (1201 Mbps on the 5 GHz band and 300 Mbps on the 2.4 GHz band)15
- Connect More Devices: Wi-Fi 6 technology transmits more data to more devices using revolutionary OFDMA and MU-MIMO technologies while reducing latency.24
- More Reliable Coverage: Get the strongest, most reliable Wi-Fi coverage with Archer AX12 as it focuses signal strength to your devices using Beamforming technology and four antennas.
- Extended Battery Life: Target Wake Time technology reduces the power consumption of your devices to extend their battery life. 3
- Easy Setup: Set up your router in minutes with the powerful TP-Link Tether app.
- Backward compatible: Archer AX12 supports all previous 802.11 standards and all Wi-Fi devices.
Product features:
| Standards | Wi-Fi 6 IEEE 802.11ax/ac/n/a 5 GHz IEEE 802.11n/b/g 2.4 GHz |
|---|---|
| Wi-Fi speeds | AX1500 5 GHz: 1201 Mbps (802.11ax) 2.4 GHz: 300 Mbps (802.11n) |
| WiFi Range | 2-3 Bedroom Homes 4× fixed high-performance antennas Multiple antennas form a signal-boosting array to cover more directions and larger areas Beamforming Concentrates wireless signal strength to client devices to extend Wi-Fi range |
| WiFi capacity | High dual-band Allocate devices to different bands for optimal performance OFDMA Communicates with multiple Wi-Fi 6 clients simultaneously Airtime Fairness Improves network efficiency by limiting over-congestion 4 streams Connect your devices to higher bandwidth |
| Operating modes | Router mode Access point mode |
| Network Security | SPI Firewall Access Control IP and MAC Address Binding Application Level Gateway |
| Guest Network | 1 × 5 GHz Guest Network 1 × 2.4 GHz Guest Network |
| VPN Server | OpenVPN PPTP |
| WiFi Encryption | WPA2-PSK WPA2-PSK/WPA-PSK WPA3-Personal WPA3-Personal/WPA2-PSK WPA2-Enterprise WPA/WPA2-Enterprise Encryption |
| Ethernet Ports | 1× Gigabit WAN Port 3× Gigabit LAN Ports |
| Buttons | WPS/Reset Button |
| Power | 12 V ⎓ 1 A |
| Protocols | IPv4 IPv6 |
| Parental Control | URL Filtering Time Control |
| WAN Types | Dynamic IP Address Static IP Address PPPoE/PPTP(Dual Access)/L2TP(Dual Access) |
| Quality of Service | QoS by Device |
| Cloud Service | Automatic Firmware Update Wireless Firmware Update TP-Link ID DDNS |
| NAT Forwarding | Port Forwarding Port Triggering DMZ UPnP |
| IPTV | IGMP Proxy IGMP Snooping Bridge Tagged VLAN |
| DHCP | Address Reservation DHCP Client List Server |
| DDNS | TP-Link NO-IP DynDNS |
| Management | Tether App Web Page |
| System Requirements | Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10/11, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 or other Java-enabled browser Cable or DSL modem Internet service provider (for Internet access) |
| Certificates | FCC, CE, RoHS |
| Environmental | Operating ambient temperature: 0℃~40℃ (32℉ ~104℉) Storage ambient temperature: -40℃~60℃ (-40℉ ~140℉) Operating Humidity: 10%~90% Non-condensing Storage Humidity: 5%~90% Non-condensing |
| WiFi Transmission Power | CE: <20dBm(2.4 GHz) <23dBm(5.15 GHz~5.25 GHz) FCC: <30dBm(2.4 GHz & 5.15 GHz~5.825 GHz) |
| WiFi Reception Sensitivity | 5 GHz: 11a 6Mbps:-95dBm, 11a 54Mbps:-79dBm 11ac VHT20_MCS0:-96dBm, 11ac VHT20_MCS8:-66dBm 11ac VHT40_MCS0:-94dBm, 11ac VHT40_MCS9:-63dBm 11ac VHT80_MCS0:-91dBm, 11ac VHT80_MCS9:-60dBm 11ax HE20_MCS0:-95dBm, 11ax HE20_MCS11:-66dBm 11ax HE40_MCS0:-92dBm, 11ax HE40_MCS11:-65dBm 11ax HE80_MCS0:-89dBm, 11ax HE80_MCS11:-62dBm 2.4 GHz: 11g 6Mbps: -96 54Mbps: -80 HT20-MCS0: -97 MCS7: -78 HT40-MCS0: -94 MCS7: -75 |
| Dimensions (WxDxH) | 8.5 × 4.6 × 1.3 inches (215 × 117 × 32 mm) |
| Package Contents | Archer AX12 Wireless Router Power Adapter RJ45 Ethernet Cable Quick Setup Guide |
| Warranty | 36 months |
